Tissue Paper Machine (from headbox to pope reeler)

Popularity
Quantity 1
Product ref. 243
Machine parameters

Prepared for speed 600 m/min Grammage 15-50 gsm
Trim at pope
2230 mm
Yankee diameter
4000 mm Yankee width 2500 mm Fourdrinier

Last improvement in 2011

Paper machine details:

The headbox - Voith, no. 1916 Size K-3 Inside 2 rectifier reels inside headbx- fi 150 and 120, highpressure oil motor pump for driving of fillgree billets of type P2RHM254 (N=1.5kW, U=380V, p=60ba, n=0-24rpm), the distributor of the paper pulp before the breast-box. The headbox lip connected with 16 regulators of the headbox lip (manual control)

1. The wire end

2. The press part- acid-proof execution

3. The drying section
